Pro SOLO mk2 MIDI to CV converter

Kenton

  • $ 23500

Pre-Order

High specification single synth MIDI to CV converter

  • Designed to control all types of mono-synth
  • Super-fast response time
  • Famous Kenton build quality
  • Rugged steel case
  • High specification 16 bit D/A converters for rock-steady pitches
  • Runs from standard 9 volt power supply, 2.1mm center positive (+)
  • MIDI IN socket
  • MIDI THRU socket can be switched to become DIN SYNC or AUX 2 & 3
  • Any MIDI channel can be selected
  • Switchable for V/oct & Hz/V & 1.2V/oct scaling systems
  • Fine tune & scale are software controllable
  • Transpose (coarse tune) - up & down 12 semitones
  • Adjustable pitchbend range
  • Programmable Gate V-trig (up to 15v) or S-trig (with or without pull-up)
  • Multiple and single trigger modes
  • Note priority selection - newest / lowest / highest
  • Old notes are remembered to facilitate trill effects and increase playability
  • Portamento - fixed rate or fixed time modes
  • Auto Portamento mode selectable (where legato playing turns on Portamento)
  • Portamento Controller is selectable
  • Programmable AUX 1 variable analogue output controllable by any MIDI controller
  • AUX 2 & 3 (if selected) are switch outputs giving +5V or zero, depending on controller value
  • Programmable LFO - 9 wave shapes inc. random
  • LFO can modulate pitch &/or AUX output
  • Separate Controllers for LFO to CV and LFO to AUX
  • LFO can be synchronised to MIDI clock
  • LFO sync point can be selected
  • Key-on can reset LFO
  • Aux1 output can output clock
  • Clock output can select from 1 to 12, 24, or 48 clocks per quarter note
  • All parameters are controllable in real-time by SysEx
  • Set-up are stored in non-volatile memory for easy recall
  • MIDI monitor mode - for easy MIDI troubleshooting
  • Power supply included - UK / EU / USA types available


What's new or different about the MkII?
  • Now runs from standard 9 volt power supply - centre positive
  • MIDI THRU socket can be switched to become DIN SYNC or AUX 2 & 3
  • Portamento - new fixed time mode as well as existing fixed rate
  • Auto Portamento mode selectable (where legato playing turns on Portamento)
  • LFO sync point can be selected
  • LFO to CV controller now has Min, Max and Reset values
  • LFO to Aux controller now has Min, Max and Reset values
  • Key-on can reset LFO
  • All parameters are controllable in real-time by SysEx
  • Aux1 output can output clock at 1 to 12, 24, or 48 clocks per quarter note
  • Din sync and clock can be used at the same time as CV and Gate outputs
  • Can control all 5 connections of a TB-303 5 Socket upgrade at the same time
  • Display now uses all three digits to display numbers
  • Box now an attractive cobalt blue colour
